Vue 实现尺子组件

实现一个尺子组件可以通过 Canvas 或纯 CSS 完成。以下是两种常见实现方式：

使用 Canvas 绘制尺子

通过 Canvas 动态绘制刻度线和数字，适合需要高精度或动态缩放场景。

<template>
  <div class="ruler-container">
    <canvas ref="canvas" :width="width" :height="height"></canvas>
  </div>
</template>

<script>
export default {
  props: {
    width: { type: Number, default: 800 },
    height: { type: Number, default: 40 },
    scale: { type: Number, default: 1 }, // 缩放比例
    startValue: { type: Number, default: 0 } // 起始刻度值
  },
  mounted() {
    this.drawRuler();
  },
  methods: {
    drawRuler() {
      const canvas = this.$refs.canvas;
      const ctx = canvas.getContext('2d');
      ctx.clearRect(0, 0, this.width, this.height);

      // 绘制背景
      ctx.fillStyle = '#f5f5f5';
      ctx.fillRect(0, 0, this.width, this.height);

      // 绘制刻度
      const pixelsPerUnit = 50 * this.scale;
      const totalUnits = Math.ceil(this.width / pixelsPerUnit);

      for (let i = 0; i <= totalUnits; i++) {
        const x = i * pixelsPerUnit;
        const isMajorTick = i % 10 === 0;

        // 刻度线高度
        const tickHeight = isMajorTick ? 20 : 10;

        // 绘制刻度线
        ctx.beginPath();
        ctx.moveTo(x, this.height);
        ctx.lineTo(x, this.height - tickHeight);
        ctx.strokeStyle = '#333';
        ctx.stroke();

        // 绘制数字
        if (isMajorTick) {
          ctx.font = '12px Arial';
          ctx.fillStyle = '#333';
          ctx.textAlign = 'center';
          ctx.fillText(
            this.startValue + i,
            x,
            this.height - tickHeight - 5
          );
        }
      }
    }
  },
  watch: {
    scale() {
      this.drawRuler();
    }
  }
};
</script>

使用 CSS 实现尺子

纯 CSS 实现适合简单场景，通过伪元素和 flex 布局生成刻度。

<template>
  <div class="css-ruler" :style="{ width: `${length}px` }">
    <div
      v-for="(tick, index) in ticks"
      :key="index"
      class="tick"
      :class="{ 'major-tick': index % 10 === 0 }"
    >
      <span v-if="index % 10 === 0">{{ index }}</span>
    </div>
  </div>
</template>

<script>
export default {
  props: {
    length: { type: Number, default: 800 }, // 尺子长度（像素）
    unit: { type: Number, default: 10 } // 每像素代表单位
  },
  computed: {
    ticks() {
      return Array(Math.floor(this.length / this.unit)).fill(0);
    }
  }
};
</script>

<style>
.css-ruler {
  display: flex;
  height: 40px;
  background: #f5f5f5;
  position: relative;
}

.tick {
  flex: 1;
  border-left: 1px solid #999;
  position: relative;
  height: 10px;
}

.major-tick {
  height: 20px;
}

.major-tick span {
  position: absolute;
  bottom: -20px;
  left: -10px;
  font-size: 12px;
}
</style>

实现交互功能

添加拖动和缩放功能需要结合鼠标事件：

// 在 Canvas 组件中添加
data() {
  return {
    isDragging: false,
    lastX: 0,
    offsetX: 0
  }
},
methods: {
  handleMouseDown(e) {
    this.isDragging = true;
    this.lastX = e.clientX;
  },
  handleMouseMove(e) {
    if (!this.isDragging) return;
    const dx = e.clientX - this.lastX;
    this.offsetX += dx;
    this.lastX = e.clientX;
    this.drawRuler();
  },
  handleMouseUp() {
    this.isDragging = false;
  }
},
mounted() {
  this.$refs.canvas.addEventListener('mousedown', this.handleMouseDown);
  window.addEventListener('mousemove', this.handleMouseMove);
  window.addEventListener('mouseup', this.handleMouseUp);
},
beforeDestroy() {
  this.$refs.canvas.removeEventListener('mousedown', this.handleMouseDown);
  window.removeEventListener('mousemove', this.handleMouseMove);
  window.removeEventListener('mouseup', this.handleMouseUp);
}

垂直尺子实现

将水平尺子逻辑调整为垂直方向，修改 Canvas 绘制逻辑或 CSS 样式：

.vertical-ruler {
  width: 40px;
  height: 500px;
  flex-direction: column;
}

.vertical-tick {
  border-left: none;
  border-top: 1px solid #999;
}

通过以上方法可以实现基础尺子功能，实际项目中可根据需求添加单位切换、主题定制等功能。Canvas 方案适合高性能需求，CSS 方案则更轻量易维护。
