vue实现关联饼图

2026-02-25 00:02:09VUE

Vue 实现关联饼图

关联饼图通常指多个饼图之间通过交互或数据联动展示关联关系。以下是基于 Vue 和 ECharts 的实现方法：

安装依赖

确保项目中已安装 ECharts 和 Vue-ECharts：

vue实现关联饼图

npm install echarts vue-echarts

基础组件封装

创建一个可复用的饼图组件（PieChart.vue）：

<template>
  <v-chart class="chart" :option="option" :autoresize="true" />
</template>

<script>
import { use } from "echarts/core";
import { PieChart } from "echarts/charts";
import {
  TitleComponent,
  TooltipComponent,
  LegendComponent
} from "echarts/components";
import { CanvasRenderer } from "echarts/renderers";
import VChart from "vue-echarts";

use([
  PieChart,
  TitleComponent,
  TooltipComponent,
  LegendComponent,
  CanvasRenderer
]);

export default {
  components: { VChart },
  props: {
    chartData: {
      type: Array,
      required: true
    },
    title: {
      type: String,
      default: ""
    }
  },
  computed: {
    option() {
      return {
        title: { text: this.title, left: "center" },
        tooltip: { trigger: "item" },
        legend: { orient: "vertical", right: 10, top: "center" },
        series: [{
          name: this.title,
          type: "pie",
          radius: ["40%", "70%"],
          avoidLabelOverlap: false,
          itemStyle: { borderRadius: 10 },
          label: { show: false },
          emphasis: { label: { show: true } },
          data: this.chartData
        }]
      };
    }
  }
};
</script>

<style scoped>
.chart {
  height: 400px;
}
</style>

实现关联交互

在父组件中实现数据联动（示例为两个关联饼图）：

vue实现关联饼图

<template>
  <div class="container">
    <pie-chart
      ref="chart1"
      :chart-data="data1"
      title="主分类"
      @chart-click="handleChartClick"
    />
    <pie-chart
      ref="chart2"
      :chart-data="data2"
      title="子分类"
    />
  </div>
</template>

<script>
import PieChart from "./PieChart.vue";

export default {
  components: { PieChart },
  data() {
    return {
      rawData: {
        "电子产品": [
          { value: 35, name: "手机" },
          { value: 25, name: "笔记本" }
        ],
        "服装": [
          { value: 30, name: "男装" },
          { value: 10, name: "女装" }
        ]
      },
      data1: [],
      data2: []
    };
  },
  mounted() {
    this.initData();
  },
  methods: {
    initData() {
      this.data1 = Object.keys(this.rawData).map(name => ({
        name,
        value: this.rawData[name].reduce((sum, item) => sum + item.value, 0)
      }));
    },
    handleChartClick(params) {
      if (params.data) {
        this.data2 = this.rawData[params.data.name];
      }
    }
  }
};
</script>

<style>
.container {
  display: flex;
  gap: 20px;
}
</style>

高级联动功能

通过 ECharts 的 connect 实现视图级联动：

// 在父组件 mounted 中添加
import { connect } from "echarts";

mounted() {
  this.$nextTick(() => {
    const chart1 = this.$refs.chart1.$refs.chart;
    const chart2 = this.$refs.chart2.$refs.chart;
    connect([chart1, chart2]);
  });
}

动态数据更新

使用 watch 实现响应式数据更新：

watch: {
  data2(newVal) {
    this.$refs.chart2.option.series[0].data = newVal;
    this.$refs.chart2.chart.setOption(this.$refs.chart2.option);
  }
}
