vue实现元素拖拽缩放

2026-02-21 07:54:55VUE

Vue 实现元素拖拽缩放

使用原生 HTML5 拖拽 API

在 Vue 中可以通过 @mousedown、@mousemove 和 @mouseup 事件监听实现拖拽功能。缩放功能可以通过监听元素的边缘或角落的拖动事件来实现。

<template>
  <div
    class="resizable-box"
    :style="{
      left: box.x + 'px',
      top: box.y + 'px',
      width: box.width + 'px',
      height: box.height + 'px'
    }"
    @mousedown="startDrag"
  >
    <div class="resizer" @mousedown="startResize"></div>
  </div>
</template>

<script>
export default {
  data() {
    return {
      box: {
        x: 100,
        y: 100,
        width: 200,
        height: 200
      },
      isDragging: false,
      isResizing: false,
      startX: 0,
      startY: 0
    };
  },
  methods: {
    startDrag(e) {
      this.isDragging = true;
      this.startX = e.clientX - this.box.x;
      this.startY = e.clientY - this.box.y;
      document.addEventListener('mousemove', this.drag);
      document.addEventListener('mouseup', this.stopDrag);
    },
    drag(e) {
      if (this.isDragging) {
        this.box.x = e.clientX - this.startX;
        this.box.y = e.clientY - this.startY;
      }
    },
    stopDrag() {
      this.isDragging = false;
      document.removeEventListener('mousemove', this.drag);
      document.removeEventListener('mouseup', this.stopDrag);
    },
    startResize(e) {
      this.isResizing = true;
      this.startX = e.clientX;
      this.startY = e.clientY;
      document.addEventListener('mousemove', this.resize);
      document.addEventListener('mouseup', this.stopResize);
    },
    resize(e) {
      if (this.isResizing) {
        this.box.width = e.clientX - this.box.x;
        this.box.height = e.clientY - this.box.y;
      }
    },
    stopResize() {
      this.isResizing = false;
      document.removeEventListener('mousemove', this.resize);
      document.removeEventListener('mouseup', this.stopResize);
    }
  }
};
</script>

<style>
.resizable-box {
  position: absolute;
  border: 1px solid #000;
  background: #f0f0f0;
  cursor: move;
}
.resizer {
  width: 10px;
  height: 10px;
  background: #000;
  position: absolute;
  right: 0;
  bottom: 0;
  cursor: nwse-resize;
}
</style>

使用第三方库 `vue-draggable-resizable`

vue-draggable-resizable 是一个专门为 Vue 设计的拖拽和缩放组件，简化了实现过程。

安装：

npm install vue-draggable-resizable

使用：

<template>
  <div>
    <VueDraggableResizable
      :w="200"
      :h="200"
      :x="100"
      :y="100"
      @dragging="onDrag"
      @resizing="onResize"
    >
      <p>可拖拽缩放的元素</p>
    </VueDraggableResizable>
  </div>
</template>

<script>
import VueDraggableResizable from 'vue-draggable-resizable';

export default {
  components: {
    VueDraggableResizable
  },
  methods: {
    onDrag(x, y) {
      console.log('拖拽位置:', x, y);
    },
    onResize(x, y, width, height) {
      console.log('缩放尺寸:', width, height);
    }
  }
};
</script>

使用 `interact.js` 实现高级交互

interact.js 是一个功能强大的拖拽、缩放和手势库，适合更复杂的交互需求。

安装：

npm install interactjs

使用：

<template>
  <div
    ref="box"
    class="draggable-box"
    :style="{
      left: box.x + 'px',
      top: box.y + 'px',
      width: box.width + 'px',
      height: box.height + 'px'
    }"
  >
    可拖拽缩放的元素
  </div>
</template>

<script>
import interact from 'interactjs';

export default {
  data() {
    return {
      box: {
        x: 100,
        y: 100,
        width: 200,
        height: 200
      }
    };
  },
  mounted() {
    interact(this.$refs.box)
      .draggable({
        onmove: (event) => {
          this.box.x += event.dx;
          this.box.y += event.dy;
        }
      })
      .resizable({
        edges: { left: true, right: true, bottom: true, top: true },
        onmove: (event) => {
          this.box.width = event.rect.width;
          this.box.height = event.rect.height;
          this.box.x += event.deltaRect.left;
          this.box.y += event.deltaRect.top;
        }
      });
  }
};
</script>

<style>
.draggable-box {
  position: absolute;
  border: 1px solid #000;
  background: #f0f0f0;
  cursor: move;
}
</style>
