vue实现拖拽框

2026-02-20 01:15:26VUE

实现拖拽框的基本思路

在Vue中实现拖拽功能，可以利用HTML5的拖放API或第三方库如vuedraggable。以下是两种常见方法的实现方式。

使用HTML5拖放API

HTML5原生提供了拖放API，通过draggable属性和相关事件实现拖拽功能。

vue实现拖拽框

<template>
  <div
    class="draggable-box"
    draggable="true"
    @dragstart="handleDragStart"
    @dragend="handleDragEnd"
    @dragover.prevent
    @drop="handleDrop"
  >
    拖拽我
  </div>
</template>

<script>
export default {
  methods: {
    handleDragStart(e) {
      e.dataTransfer.setData('text/plain', e.target.id);
      e.target.style.opacity = '0.4';
    },
    handleDragEnd(e) {
      e.target.style.opacity = '1';
    },
    handleDrop(e) {
      e.preventDefault();
      const data = e.dataTransfer.getData('text/plain');
      e.target.appendChild(document.getElementById(data));
    }
  }
};
</script>

<style>
.draggable-box {
  width: 100px;
  height: 100px;
  background-color: #42b983;
  color: white;
  display: flex;
  align-items: center;
  justify-content: center;
  cursor: move;
}
</style>

使用vuedraggable库

vuedraggable是一个基于Sortable.js的Vue拖拽组件，适合列表拖拽或复杂场景。

安装依赖：

vue实现拖拽框

npm install vuedraggable

示例代码：

<template>
  <draggable
    v-model="list"
    @start="dragStart"
    @end="dragEnd"
  >
    <div v-for="item in list" :key="item.id" class="draggable-item">
      {{ item.name }}
    </div>
  </draggable>
</template>

<script>
import draggable from 'vuedraggable';

export default {
  components: { draggable },
  data() {
    return {
      list: [
        { id: 1, name: 'Item 1' },
        { id: 2, name: 'Item 2' },
        { id: 3, name: 'Item 3' }
      ]
    };
  },
  methods: {
    dragStart() {
      console.log('拖拽开始');
    },
    dragEnd() {
      console.log('拖拽结束');
    }
  }
};
</script>

<style>
.draggable-item {
  padding: 10px;
  margin: 5px;
  background-color: #f0f0f0;
  cursor: move;
}
</style>

实现边界限制

如果需要限制拖拽范围，可以通过计算位置并动态调整元素样式。

<template>
  <div
    class="draggable-container"
    @mousedown="startDrag"
    @mousemove="onDrag"
    @mouseup="stopDrag"
    :style="{ left: position.x + 'px', top: position.y + 'px' }"
  >
    拖拽我（限制边界）
  </div>
</template>

<script>
export default {
  data() {
    return {
      position: { x: 0, y: 0 },
      isDragging: false,
      startPos: { x: 0, y: 0 }
    };
  },
  methods: {
    startDrag(e) {
      this.isDragging = true;
      this.startPos = {
        x: e.clientX - this.position.x,
        y: e.clientY - this.position.y
      };
    },
    onDrag(e) {
      if (!this.isDragging) return;
      const maxX = window.innerWidth - 100;
      const maxY = window.innerHeight - 100;
      this.position.x = Math.min(Math.max(0, e.clientX - this.startPos.x), maxX);
      this.position.y = Math.min(Math.max(0, e.clientY - this.startPos.y), maxY);
    },
    stopDrag() {
      this.isDragging = false;
    }
  }
};
</script>

<style>
.draggable-container {
  position: absolute;
  width: 100px;
  height: 100px;
  background-color: #ff7f50;
  color: white;
  display: flex;
  align-items: center;
  justify-content: center;
  cursor: move;
}
</style>
