vue 实现电子签名

实现电子签名的基础方法

使用Vue实现电子签名功能，可以通过HTML5的Canvas元素结合触摸或鼠标事件完成。核心步骤包括初始化画布、监听绘制事件、保存签名数据。

<template>
  <div>
    <canvas
      ref="signaturePad"
      @mousedown="startDrawing"
      @mousemove="draw"
      @mouseup="stopDrawing"
      @touchstart="startDrawing"
      @touchmove="draw"
      @touchend="stopDrawing">
    </canvas>
    <button @click="clearSignature">清除</button>
    <button @click="saveSignature">保存</button>
  </div>
</template>

<script>
export default {
  data() {
    return {
      isDrawing: false,
      canvas: null,
      ctx: null
    };
  },
  mounted() {
    this.canvas = this.$refs.signaturePad;
    this.ctx = this.canvas.getContext('2d');
    this.resizeCanvas();
    window.addEventListener('resize', this.resizeCanvas);
  },
  methods: {
    resizeCanvas() {
      this.canvas.width = this.canvas.offsetWidth;
      this.canvas.height = this.canvas.offsetHeight;
    },
    startDrawing(e) {
      this.isDrawing = true;
      const pos = this.getPosition(e);
      this.ctx.beginPath();
      this.ctx.moveTo(pos.x, pos.y);
    },
    draw(e) {
      if (!this.isDrawing) return;
      const pos = this.getPosition(e);
      this.ctx.lineTo(pos.x, pos.y);
      this.ctx.stroke();
    },
    stopDrawing() {
      this.isDrawing = false;
    },
    getPosition(e) {
      const rect = this.canvas.getBoundingClientRect();
      return {
        x: (e.clientX || e.touches[0].clientX) - rect.left,
        y: (e.clientY || e.touches[0].clientY) - rect.top
      };
    },
    clearSignature() {
      this.ctx.clearRect(0, 0, this.canvas.width, this.canvas.height);
    },
    saveSignature() {
      const dataURL = this.canvas.toDataURL('image/png');
      console.log(dataURL); // 可上传至服务器或本地保存
    }
  }
};
</script>

<style scoped>
canvas {
  border: 1px solid #000;
  width: 100%;
  height: 300px;
  background-color: #f8f8f8;
}
</style>

使用第三方库优化体验

对于更专业的签名处理，可使用现成库如signature_pad：

1. 安装依赖：



   npm install signature_pad

2. 组件实现：


   <template>
   <div>
    <canvas ref="signatureCanvas"></canvas>
    <button @click="clear">清除</button>
    <button @click="save">保存</button>
   </div>
   </template>

import SignaturePad from 'signature_pad';

export default { data() { return { signaturePad: null }; }, mounted() { const canvas = this.$refs.signatureCanvas; canvas.width = canvas.offsetWidth; canvas.height = canvas.offsetHeight; this.signaturePad = new SignaturePad(canvas); }, methods: { clear() { this.signaturePad.clear(); }, save() { if (this.signaturePad.isEmpty()) { alert('请先签名'); return; } const data = this.signaturePad.toDataURL(); console.log(data); } } };

```

移动端适配要点

1. 防止触摸滚动：在画布上添加@touchmove.prevent修饰符
2. 笔迹平滑：调整signature_pad的throttle和minWidth参数
3. 响应式设计：监听窗口变化自动调整画布尺寸

mounted() {
  this.initSignaturePad();
  window.addEventListener('resize', this.handleResize);
},
methods: {
  initSignaturePad() {
    const canvas = this.$refs.signatureCanvas;
    this.signaturePad = new SignaturePad(canvas, {
      minWidth: 1,
      maxWidth: 3,
      throttle: 16
    });
    this.handleResize();
  },
  handleResize() {
    const canvas = this.$refs.signatureCanvas;
    canvas.width = canvas.offsetWidth;
    canvas.height = canvas.offsetHeight;
    this.signaturePad.clear(); // 防止缩放导致笔迹变形
  }
}

签名数据后端处理

保存的Base64数据可通过以下方式处理：

1. 前端转换：将Base64转为Blob对象上传

   function dataURLToBlob(dataURL) {
   const arr = dataURL.split(',');
   const mime = arr[0].match(/:(.*?);/)[1];
   const bstr = atob(arr[1]);
   let n = bstr.length;
   const u8arr = new Uint8Array(n);
   while (n--) {
    u8arr[n] = bstr.charCodeAt(n);
   }
   return new Blob([u8arr], { type: mime });
   }

2. 后端验证：检查签名图片的有效性（非空白）

   isEmpty() {
   return this.signaturePad.isEmpty();
   }

高级功能扩展

1. 笔迹颜色设置：通过penColor参数调整
2. 背景网格：在Canvas底层绘制辅助线
3. 压力感应：支持数位板压感（需浏览器支持）
4. 时间戳水印：在保存时添加签名时间信息

// 设置笔迹颜色示例
setPenColor(color) {
  this.signaturePad.penColor = color;
}

以上方案可根据实际需求组合使用，纯前端实现适合简单场景，结合后端存储则能实现完整电子签名流程。
