Vue 实现刷卡考勤系统

系统架构设计

刷卡考勤系统通常需要前后端配合实现。Vue作为前端框架负责界面交互，后端处理数据存储和逻辑验证。

前端实现步骤

安装必要依赖

npm install axios vue-router vuex

创建考勤页面组件

<template>
  <div class="attendance-container">
    <h3>刷卡考勤系统</h3>
    <div class="card-reader">
      <input
        type="text"
        v-model="cardId"
        placeholder="请刷卡或输入卡号"
        @keyup.enter="handleAttendance"
      />
    </div>
    <div class="result-message" :class="{'success': isSuccess, 'error': isError}">
      {{ message }}
    </div>
  </div>
</template>

<script>
export default {
  data() {
    return {
      cardId: '',
      message: '',
      isSuccess: false,
      isError: false
    }
  },
  methods: {
    async handleAttendance() {
      try {
        const response = await axios.post('/api/attendance', {
          cardId: this.cardId,
          timestamp: new Date().toISOString()
        });

        this.message = response.data.message;
        this.isSuccess = true;
        this.isError = false;

        // 3秒后清空输入框
        setTimeout(() => {
          this.cardId = '';
        }, 3000);
      } catch (error) {
        this.message = error.response.data.error || '考勤失败';
        this.isError = true;
        this.isSuccess = false;
      }
    }
  }
}
</script>

配置路由

// router/index.js
import Attendance from '../views/Attendance.vue'

const routes = [
  {
    path: '/attendance',
    name: 'Attendance',
    component: Attendance
  }
]

后端接口设计

基本考勤接口

// Node.js示例
router.post('/api/attendance', async (req, res) => {
  const { cardId, timestamp } = req.body;

  try {
    // 验证卡号有效性
    const employee = await Employee.findOne({ cardId });
    if (!employee) {
      return res.status(400).json({ error: '无效卡号' });
    }

    // 记录考勤
    const record = new AttendanceRecord({
      employeeId: employee._id,
      checkInTime: new Date(timestamp),
      status: '正常'
    });

    await record.save();
    res.json({ message: `考勤成功，欢迎${employee.name}` });
  } catch (err) {
    res.status(500).json({ error: '服务器错误' });
  }
});

硬件集成方案

串口通信方案

// 使用serialport库与读卡器通信
const SerialPort = require('serialport');
const Readline = require('@serialport/parser-readline');

const port = new SerialPort('/dev/ttyUSB0', { baudRate: 9600 });
const parser = port.pipe(new Readline({ delimiter: '\r\n' }));

parser.on('data', (cardId) => {
  // 将卡号发送到前端
  io.emit('card-read', cardId.trim());
});

前端接收硬件信号

// 使用Socket.io接收实时卡号
import io from 'socket.io-client';

export default {
  created() {
    this.socket = io('http://localhost:3000');
    this.socket.on('card-read', (cardId) => {
      this.cardId = cardId;
      this.handleAttendance();
    });
  }
}

数据可视化

考勤记录展示

<template>
  <div class="records-container">
    <h3>考勤记录</h3>
    <table>
      <thead>
        <tr>
          <th>员工姓名</th>
          <th>刷卡时间</th>
          <th>状态</th>
        </tr>
      </thead>
      <tbody>
        <tr v-for="record in records" :key="record._id">
          <td>{{ record.employee.name }}</td>
          <td>{{ formatDate(record.checkInTime) }}</td>
          <td>{{ record.status }}</td>
        </tr>
      </tbody>
    </table>
  </div>
</template>

<script>
export default {
  data() {
    return {
      records: []
    }
  },
  async created() {
    const response = await axios.get('/api/attendance/records');
    this.records = response.data;
  },
  methods: {
    formatDate(dateString) {
      return new Date(dateString).toLocaleString();
    }
  }
}
</script>

安全增强措施

防止重复刷卡

// 后端验证逻辑
const existingRecord = await AttendanceRecord.findOne({
  employeeId: employee._id,
  checkInTime: {
    $gte: new Date().setHours(0, 0, 0, 0),
    $lt: new Date().setHours(23, 59, 59, 999)
  }
});

if (existingRecord) {
  return res.status(400).json({ error: '今日已打卡' });
}

数据加密传输

// 前端axios配置
axios.defaults.baseURL = 'https://your-domain.com/api';
axios.defaults.headers.common['Authorization'] = `Bearer ${token}`;

扩展功能

考勤统计报表

// 后端统计接口
router.get('/api/attendance/stats', async (req, res) => {
  const stats = await AttendanceRecord.aggregate([
    {
      $match: {
        checkInTime: {
          $gte: new Date(req.query.startDate),
          $lt: new Date(req.query.endDate)
        }
      }
    },
    {
      $group: {
        _id: "$employeeId",
        count: { $sum: 1 },
        lateCount: {
          $sum: {
            $cond: [{ $eq: ["$status", "迟到"] }, 1, 0]
          }
        }
      }
    }
  ]);

  res.json(stats);
});

移动端适配

/* 响应式设计 */
@media (max-width: 768px) {
  .attendance-container {
    padding: 10px;
  }

  input[type="text"] {
    width: 90%;
    font-size: 16px;
  }
}

该系统实现方案涵盖了从硬件集成到前后端开发的完整流程，可根据实际需求进行扩展和调整。
