vue如何实现曲线图

使用 ECharts 实现曲线图

在 Vue 项目中安装 ECharts 依赖：

npm install echarts --save

引入 ECharts 并创建基础图表组件：

<template>
  <div ref="chart" style="width: 600px; height: 400px;"></div>
</template>

<script>
import * as echarts from 'echarts';

export default {
  mounted() {
    this.initChart();
  },
  methods: {
    initChart() {
      const chartDom = this.$refs.chart;
      const myChart = echarts.init(chartDom);

      const option = {
        xAxis: {
          type: 'category',
          data: ['Mon', 'Tue', 'Wed', 'Thu', 'Fri', 'Sat', 'Sun']
        },
        yAxis: {
          type: 'value'
        },
        series: [{
          data: [820, 932, 901, 934, 1290, 1330, 1320],
          type: 'line',
          smooth: true
        }]
      };

      myChart.setOption(option);
    }
  }
}
</script>

使用 Vue-ECharts 封装组件

安装 vue-echarts 封装库：

npm install echarts vue-echarts

创建可复用的曲线图组件：

<template>
  <v-chart :option="chartOptions" autoresize />
</template>

<script>
import { use } from 'echarts/core';
import { CanvasRenderer } from 'echarts/renderers';
import { LineChart } from 'echarts/charts';
import {
  TitleComponent,
  TooltipComponent,
  GridComponent
} from 'echarts/components';
import VChart from 'vue-echarts';

use([
  CanvasRenderer,
  LineChart,
  TitleComponent,
  TooltipComponent,
  GridComponent
]);

export default {
  components: { VChart },
  data() {
    return {
      chartOptions: {
        title: { text: '销售趋势' },
        tooltip: { trigger: 'axis' },
        xAxis: {
          data: ['1月', '2月', '3月', '4月', '5月', '6月']
        },
        yAxis: {},
        series: [{
          name: '销售额',
          type: 'line',
          data: [120, 200, 150, 80, 70, 110],
          smooth: true,
          areaStyle: {
            color: new echarts.graphic.LinearGradient(0, 0, 0, 1, [
              { offset: 0, color: 'rgba(58, 77, 233, 0.8)' },
              { offset: 1, color: 'rgba(58, 77, 233, 0.1)' }
            ])
          }
        }]
      }
    };
  }
};
</script>

动态数据更新处理

实现响应式数据更新：

<script>
export default {
  data() {
    return {
      chartData: {
        dates: [],
        values: []
      }
    }
  },
  methods: {
    fetchData() {
      // 模拟API请求
      setTimeout(() => {
        this.chartData = {
          dates: ['Q1', 'Q2', 'Q3', 'Q4'],
          values: [300, 280, 900, 1200]
        };
        this.updateChart();
      }, 1000);
    },
    updateChart() {
      this.chartOptions = {
        xAxis: { data: this.chartData.dates },
        series: [{
          data: this.chartData.values
        }]
      };
    }
  },
  mounted() {
    this.fetchData();
  }
}
</script>

多曲线配置示例

配置包含多条曲线的图表：

chartOptions: {
  legend: {
    data: ['邮件营销', '联盟广告', '视频广告']
  },
  xAxis: { type: 'category', data: ['1月','2月','3月','4月','5月','6月'] },
  yAxis: { type: 'value' },
  series: [
    {
      name: '邮件营销',
      type: 'line',
      stack: '总量',
      data: [120, 132, 101, 134, 90, 230]
    },
    {
      name: '联盟广告',
      type: 'line',
      stack: '总量',
      data: [220, 182, 191, 234, 290, 330]
    },
    {
      name: '视频广告',
      type: 'line',
      stack: '总量',
      data: [150, 232, 201, 154, 190, 330]
    }
  ]
}

性能优化建议

对于大数据量场景使用增量渲染：

series: [{
  type: 'line',
  data: largeDataArray,
  progressive: 1000,
  progressiveThreshold: 3000
}]

添加窗口大小变化监听：

mounted() {
  window.addEventListener('resize', this.handleResize);
  this.initChart();
},
beforeDestroy() {
  window.removeEventListener('resize', this.handleResize);
},
methods: {
  handleResize() {
    this.myChart && this.myChart.resize();
  }
}
