js实现画图

2026-01-30 09:16:07JavaScript

使用Canvas API绘制图形

Canvas API是HTML5提供的原生绘图工具，通过JavaScript操作<canvas>元素实现2D图形绘制。基础步骤如下：

创建一个HTML文件并添加<canvas>元素：

<canvas id="myCanvas" width="500" height="500"></canvas>

JavaScript获取画布上下文并绘制图形：

js实现画图

const canvas = document.getElementById('myCanvas');
const ctx = canvas.getContext('2d');

// 绘制矩形
ctx.fillStyle = 'blue';
ctx.fillRect(50, 50, 100, 100);

// 绘制圆形
ctx.beginPath();
ctx.arc(200, 200, 50, 0, Math.PI * 2);
ctx.fillStyle = 'red';
ctx.fill();

使用SVG动态生成矢量图形

通过JavaScript操作SVG DOM元素实现可缩放的矢量图形：

const svgNS = "http://www.w3.org/2000/svg";
const svg = document.createElementNS(svgNS, "svg");
svg.setAttribute('width', '500');
svg.setAttribute('height', '500');
document.body.appendChild(svg);

// 创建圆形
const circle = document.createElementNS(svgNS, "circle");
circle.setAttribute('cx', '100');
circle.setAttribute('cy', '100');
circle.setAttribute('r', '50');
circle.setAttribute('fill', 'green');
svg.appendChild(circle);

第三方库实现高级绘图

Chart.js（适合数据可视化）：

js实现画图

import Chart from 'chart.js/auto';

const ctx = document.getElementById('chart').getContext('2d');
new Chart(ctx, {
  type: 'bar',
  data: {
    labels: ['A', 'B', 'C'],
    datasets: [{
      label: 'Data',
      data: [10, 20, 30],
      backgroundColor: ['red', 'blue', 'yellow']
    }]
  }
});

p5.js（创意绘图）：

function setup() {
  createCanvas(400, 400);
}

function draw() {
  background(220);
  ellipse(mouseX, mouseY, 80, 80);
}

实现交互式绘图板

结合鼠标事件实现简单绘图功能：

const canvas = document.getElementById('drawCanvas');
const ctx = canvas.getContext('2d');
let isDrawing = false;

canvas.addEventListener('mousedown', startDrawing);
canvas.addEventListener('mousemove', draw);
canvas.addEventListener('mouseup', stopDrawing);

function startDrawing(e) {
  isDrawing = true;
  ctx.beginPath();
  ctx.moveTo(e.offsetX, e.offsetY);
}

function draw(e) {
  if (!isDrawing) return;
  ctx.lineTo(e.offsetX, e.offsetY);
  ctx.strokeStyle = '#000';
  ctx.lineWidth = 5;
  ctx.stroke();
}

function stopDrawing() {
  isDrawing = false;
}

WebGL实现3D绘图

通过Three.js简化WebGL操作：

import * as THREE from 'three';

const scene = new THREE.Scene();
const camera = new THREE.PerspectiveCamera(75, window.innerWidth/window.innerHeight, 0.1, 1000);
const renderer = new THREE.WebGLRenderer();
renderer.setSize(window.innerWidth, window.innerHeight);
document.body.appendChild(renderer.domElement);

const geometry = new THREE.BoxGeometry();
const material = new THREE.MeshBasicMaterial({ color: 0x00ff00 });
const cube = new THREE.Mesh(geometry, material);
scene.add(cube);

camera.position.z = 5;

function animate() {
  requestAnimationFrame(animate);
  cube.rotation.x += 0.01;
  cube.rotation.y += 0.01;
  renderer.render(scene, camera);
}
animate();
