Vue 实现扇形进度条

使用 SVG 绘制扇形

SVG 的 path 元素可以用于绘制扇形。通过计算扇形的路径数据，结合 Vue 的动态数据绑定实现进度变化。

<template>
  <svg width="200" height="200" viewBox="0 0 100 100">
    <path :d="getSectorPath(50, 50, 40, 0, endAngle)" fill="#4CAF50"/>
  </svg>
</template>

<script>
export default {
  data() {
    return {
      progress: 75, // 进度百分比 (0-100)
    };
  },
  computed: {
    endAngle() {
      return (this.progress / 100) * 2 * Math.PI;
    },
  },
  methods: {
    getSectorPath(cx, cy, r, startAngle, endAngle) {
      const x1 = cx + r * Math.cos(startAngle);
      const y1 = cy + r * Math.sin(startAngle);
      const x2 = cx + r * Math.cos(endAngle);
      const y2 = cy + r * Math.sin(endAngle);
      const largeArcFlag = endAngle - startAngle <= Math.PI ? 0 : 1;
      return `M ${cx} ${cy} L ${x1} ${y1} A ${r} ${r} 0 ${largeArcFlag} 1 ${x2} ${y2} Z`;
    },
  },
};
</script>

使用 Canvas 绘制扇形

通过 Canvas 的 arc 方法绘制扇形，结合 Vue 的响应式特性更新绘制。

<template>
  <canvas ref="canvas" width="200" height="200"></canvas>
</template>

<script>
export default {
  data() {
    return {
      progress: 75,
    };
  },
  mounted() {
    this.drawSector();
  },
  watch: {
    progress() {
      this.drawSector();
    },
  },
  methods: {
    drawSector() {
      const canvas = this.$refs.canvas;
      const ctx = canvas.getContext('2d');
      const centerX = canvas.width / 2;
      const centerY = canvas.height / 2;
      const radius = 80;
      const startAngle = 0;
      const endAngle = (this.progress / 100) * 2 * Math.PI;

      ctx.clearRect(0, 0, canvas.width, canvas.height);
      ctx.beginPath();
      ctx.moveTo(centerX, centerY);
      ctx.arc(centerX, centerY, radius, startAngle, endAngle);
      ctx.closePath();
      ctx.fillStyle = '#4CAF50';
      ctx.fill();
    },
  },
};
</script>

使用第三方库

可以借助第三方库如 vue-awesome-progress 或 echarts 快速实现扇形进度条。

使用 echarts 的示例：

<template>
  <div ref="chart" style="width: 200px; height: 200px;"></div>
</template>

<script>
import * as echarts from 'echarts';
export default {
  data() {
    return {
      progress: 75,
    };
  },
  mounted() {
    this.initChart();
  },
  watch: {
    progress() {
      this.initChart();
    },
  },
  methods: {
    initChart() {
      const chart = echarts.init(this.$refs.chart);
      chart.setOption({
        series: [{
          type: 'pie',
          radius: ['60%', '80%'],
          avoidLabelOverlap: false,
          itemStyle: {
            borderRadius: 0,
            borderColor: '#fff',
            borderWidth: 2
          },
          label: {
            show: false,
          },
          data: [
            { value: this.progress, name: 'Progress' },
            { value: 100 - this.progress, name: 'Remaining' }
          ]
        }]
      });
    },
  },
};
</script>

动画效果

通过 CSS 或 JavaScript 为扇形进度条添加动画效果，提升用户体验。

// 在 drawSector 方法中添加动画
drawSector() {
  const canvas = this.$refs.canvas;
  const ctx = canvas.getContext('2d');
  const centerX = canvas.width / 2;
  const centerY = canvas.height / 2;
  const radius = 80;
  let currentAngle = 0;
  const targetAngle = (this.progress / 100) * 2 * Math.PI;

  const animate = () => {
    ctx.clearRect(0, 0, canvas.width, canvas.height);
    ctx.beginPath();
    ctx.moveTo(centerX, centerY);
    ctx.arc(centerX, centerY, radius, 0, currentAngle);
    ctx.closePath();
    ctx.fillStyle = '#4CAF50';
    ctx.fill();

    if (currentAngle < targetAngle) {
      currentAngle += 0.05;
      requestAnimationFrame(animate);
    }
  };
  animate();
}
