react 如何使用canvas

2026-02-26 05:25:45React

在 React 中使用 Canvas

React 中可以通过 useRef 和 useEffect 结合原生 Canvas API 实现绘图功能。以下是一个完整的实现方法：

创建 Canvas 组件

import React, { useRef, useEffect } from 'react';

function Canvas() {
  const canvasRef = useRef(null);

  useEffect(() => {
    const canvas = canvasRef.current;
    const ctx = canvas.getContext('2d');

    // 绘制矩形
    ctx.fillStyle = 'green';
    ctx.fillRect(10, 10, 150, 100);
  }, []);

  return (
    <canvas
      ref={canvasRef}
      width={300}
      height={200}
    />
  );
}

export default Canvas;

处理动态绘图

对于需要响应状态变化的绘图，可以将状态添加到依赖数组中：

react 如何使用canvas

function DynamicCanvas({ color }) {
  const canvasRef = useRef(null);

  useEffect(() => {
    const canvas = canvasRef.current;
    const ctx = canvas.getContext('2d');

    ctx.clearRect(0, 0, canvas.width, canvas.height);
    ctx.fillStyle = color;
    ctx.fillRect(10, 10, 150, 100);
  }, [color]);

  return <canvas ref={canvasRef} width={300} height={200} />;
}

实现动画效果

使用 requestAnimationFrame 实现动画：

function AnimatedCanvas() {
  const canvasRef = useRef(null);
  const positionRef = useRef(0);

  useEffect(() => {
    const canvas = canvasRef.current;
    const ctx = canvas.getContext('2d');

    let animationId;
    const animate = () => {
      ctx.clearRect(0, 0, canvas.width, canvas.height);
      ctx.fillRect(positionRef.current, 50, 50, 50);
      positionRef.current += 1;
      if (positionRef.current < canvas.width) {
        animationId = requestAnimationFrame(animate);
      }
    };

    animate();
    return () => cancelAnimationFrame(animationId);
  }, []);

  return <canvas ref={canvasRef} width={300} height={200} />;
}

处理用户交互

添加事件监听器处理用户输入：

react 如何使用canvas

function InteractiveCanvas() {
  const canvasRef = useRef(null);
  const [circles, setCircles] = useState([]);

  useEffect(() => {
    const canvas = canvasRef.current;
    const ctx = canvas.getContext('2d');

    const handleClick = (e) => {
      const rect = canvas.getBoundingClientRect();
      const x = e.clientX - rect.left;
      const y = e.clientY - rect.top;
      setCircles([...circles, { x, y }]);
    };

    canvas.addEventListener('click', handleClick);
    return () => canvas.removeEventListener('click', handleClick);
  }, [circles]);

  useEffect(() => {
    const canvas = canvasRef.current;
    const ctx = canvas.getContext('2d');

    ctx.clearRect(0, 0, canvas.width, canvas.height);
    circles.forEach(circle => {
      ctx.beginPath();
      ctx.arc(circle.x, circle.y, 20, 0, 2 * Math.PI);
      ctx.fill();
    });
  }, [circles]);

  return <canvas ref={canvasRef} width={500} height={400} />;
}
